Product Details
Place of Origin: China
Brand Name: Weldsuccess
Certification: ISO/CE/CO
Model Number: HGK-20
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: 15 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 5 Sets Per Month
Turning Capacity: |
20 Ton Maximum |
Drive Load Capacity: |
10 Ton Maximum |
Idler Load Capacity: |
10 Ton Maximum |
Type: |
Tank Turning Rollers |
Vessel Size: |
500~3500mm |
Rotation Power: |
2*1.1 KW |
Adjust Way: |
Bolt Adjustment |
Color: |
Customized |
Warranty: |
1 Year |
Turning Capacity: |
20 Ton Maximum |
Drive Load Capacity: |
10 Ton Maximum |
Idler Load Capacity: |
10 Ton Maximum |
Type: |
Tank Turning Rollers |
Vessel Size: |
500~3500mm |
Rotation Power: |
2*1.1 KW |
Adjust Way: |
Bolt Adjustment |
Color: |
Customized |
Warranty: |
1 Year |
1.The upper surface of pedestal is fine machined, both side of which has adjusting bolt holes.
2.It is the frame structure, scientific and reliable design.
3.Every motion part for equipment has the full lubricating system.
4.Double motors to ensure turing stably.
| Model | CR-20 |
|---|---|
|
Turning Capacity |
20 Ton Maximum |
|
Drive Load Capacity |
10 Ton Maximum |
|
Idler Load Capacity |
10Ton Maximum |
|
Adjust Way |
Bolt Adjustment |
|
Motor Power |
2*1.1KW |
|
Vessel Diameter |
500-3500mm |
|
Rotation Speed |
100-1000mm/min |
|
Speed control |
Variable frequency driver |
|
Roller wheels |
PU |
|
Roller size |
Ø350*180mm |
|
Voltage |
380v±10% 50Hz 3Phase |
|
Control system |
Foot pedal 8m cable |
|
Color |
Customized |
| Warranty | 1 Year |
